RAM Short Socket Arm with Round Plate C (RAM-103U-B)

Included:

• 1 × RAM Short Clamp Arm C Size 1.5" (RAM-201U-B)
• 1 × RAM Round Base with 1.5" C Ball (RAM-202U)

A short C-size socket arm and round adapter plate for connecting a compatible plate-backed device holder to a separate RAM C-size ball base. The open lower socket lets you choose the mounting base for your installation.

Supplied as genuine RAM components matching the official RAM-103U-B configuration. Packaging may vary. Mounting base, device holder and device are sold separately.

Specifications

• Ball and Socket Size: C size, 1.5 inches (38.1 mm).
• Arm Reach: Short; 2.5 inches (63.5 mm) socket-to-socket.
• Adapter Pattern: 4-hole AMPS: 1.181 × 1.496 inches (30 × 38 mm), plus 3 holes at 120 degrees on a 1.812-inch (46 mm) circle.
• Plate Diameter: 2.5 inches (63.5 mm).
• Material: Marine-grade aluminium.
• RAM Weight Rating: 4 lb (1.81 kg) standard use; 3 lb (1.36 kg) heavy-duty use.

Help

Use the selected holder’s specified attachment screws and nuts, including the correct screw length for its adapter connection. RAM holders commonly include their own assembly hardware; separate holder attachment fasteners are not listed as included here. Choose a mounting base that suits your mounting surface and the full holder, case and device load.

Assess reach, vibration and mounting-surface strength as well as the component rating. Check joints and fasteners before use.

Compatibility

The lower socket accepts a 1.5-inch C-size RAM ball. The supplied round plate attaches to a holder with a matching AMPS pattern. A 1-inch B-size ball does not fit this C-size arm. Check the chosen holder’s device and case dimensions separately.
