RAM Double Ball Mount B Size with Backing Plate (RAM-B-101U-225B2)

Included:

• 1 x RAM Standard Socket Arm Two Round Bases B (RAM-B-101U)
• 1 x RAM Backing Plate Adapter 2.10" x 2.60" (RAM-202-225B-2U)

The RAM-B-101U-225B2 consists of a double socket arm, two 2.5" diameter round bases that contain the universal AMPS hole pattern, a 2.10" x 2.60" backing plate, and mounting hardware.

The mount is designed with a 1" diameter rubber ball and socket system that features adjustment points at both ends of the double socket arm, allowing for near-infinite adjustability for ideal viewing angles.

Features

• 2.10" x 2.60" steel backing plate attaches to a variety of RAM^® Mounts ball bases
• 2.5" round plate with B size 1" RAM^® rubber ball connects to RAM^® device holders containing the universal AMPS hole pattern; includes B size medium length double socket arm
• Made of stainless steel and high-strength composites for durability and reliability in the most demanding environments
• Backed by a lifetime warranty

Specs

Hardware Included

• (1) Steel backing plate, 2.10 x 2.60" (53.3 x 66.0 mm)

• (4) #8-32 x 1" screws (25.4 mm)

• (4) #8 split lock washers

• (4) #8 flat washers

Product Dimensions

• Overall height: 5" (127 mm)

Socket to Socket Length

• 3" (76.2 mm)

Hole Pattern

• 4-hole AMPS, 1.181 x 1.496" (30.0 x 38.0 mm)

• 3-hole, 120 degree, 1.812" diameter (46.0 mm)

Plate Size

• 2.5" round plate (63.5 mm)

• 2.10" x 2.60" steel backing plate

Ball Size

• B Size, 1" (25.4 mm)

Weight Capacity

• Standard use: 2 lb (0.9 kg)

• Heavy duty use: 1 lb (0.45 kg)

Materials

• Marine grade aluminum

• Stainless steel

Packaging Type

• Poly bag

Weight

• 0.84 lb (0.38 kg)

RAM^® double socket arms with their distinctive Hourglass Shape are designed and recognised to provide the best possible performance for almost any application. The Hourglass Shape is a registered trademark of National Products Inc.

Note: The "U" in the part number reflects product packaged in poly bag.
