RAM-111BTU
RAM 6.25" x 2" Rectangular Plate Adapter for Swing Arms (RAM-111BTU)
$44.00$46.00You Save 4% ($2.00)
Included:
- 1 x RAM 6.25" x 2" Rectangular Plate Adapter for Swing Arms (RAM-111BTU)
The RAM-111BTU connects your fishfinder, chartplotter or radio bracket to a compatible RAM-109 series swing arm. Its rectangular plate offers multiple pre-drilled mounting holes.
The fixed post beneath the plate slides into the arm and is secured by the included upper tightening knob. Swing arm, mounting base and electronic device are sold separately. The faded components in the installation image are shown for reference only.
Specs
- Plate size: 158.75mm x 50.8mm (6.25" x 2")
- Material: Marine-grade aluminium
- Weight: Approx. 222g (0.49 lb)
- Knob thread: 5/16"-18 with 31.75mm (1.25") stud
- Packaging: Poly bag
- Warranty: RAM lifetime warranty
Hardware Included:
- 1 x 5/16"-18 x 1.25" tightening knob
- 1 x 2" nylon washer
- 1 x 1.7" nylon washer
- 1 x 5/16" stainless steel washer
- 1 x 0.77" nylon washer
Compatibility
Designed for RAM-109 series swing arms, including the RAM-109-1APU curved arm.
Supports selected Garmin, Lowrance, Humminbird and Raymarine fishfinder or chartplotter brackets, plus CB and ham radio gimbal brackets. Check your bracket's mounting-hole spacing before ordering. Some applications require additional holes to be drilled in the plate.
Garmin
GPSMAP 722xs, GPSMAP 723, GPSMAP 723xsv, GPSMAP 742xs, GPSMAP 743, GPSMAP 743xsv, Striker Plus 5cv, Striker Vivid 5cv, Striker Plus 7cv, Striker Plus 7sv, Striker Vivid 5cv, Striker Vivid 7cv, Striker Vivid 7sv, Fishfinders and GPS Chartplotters
Lowrance
Elite FS 7, HDS Carbon 7, HDS LIVE 7, Hook Reveal 7 Series, Hook Reveal 9 Series, Fishfinders and GPS Chartplotters
Humminbird
Fishfinders and GPS Chartplotters
Raymarine
Fishfinders and GPS Chartplotters
Help
Replacing the upper connection? This product includes the complete plate, tightening knob and listed washers. It is not a knob-only pack.
Not sure which component you need? Contact us with your mount model and a photo of the connection.
