RAM Stubby Cup Holder Mount w X-Grip for 7"-8" Tablets (RAP-B-299-4-UN8U)

Included:

• 1 x RAM X-Grip Small Tablet Holder w 1" Ball (RAM-HOL-UN8BU)
• 1 x RAM Standard Composite Clamp Arm B Size (RAP-B-201U)
• 1 x RAM Stubby Cup Holder Base (RAP-B-299-4U)

A complete RAM X-Grip UN8 tablet mount with a Stubby cup holder base and standard-length composite B size arm. The holder’s built-in 1" ball connects directly to the arm, with no separate cradle adapter required.

The spring-loaded X-Grip expands around your tablet, with rubber-tipped grips that leave the screen accessible. Rear grip knobs make it easy to release the tablet. The ball-and-socket joints at both ends of the arm let you adjust the viewing angle. The Stubby base has flexible support fins that can be trimmed to suit the cup holder.

Tablet and case are not included. The base fits cup holders with an inside diameter of 2.57"–3.5" (65.3–88.9mm). Check the opening, shape and usable depth, then confirm a firm fit and clearance around the gear selector and controls.

Cradle Dimensions

• Width Range: 2.5"–5.75" (63.5–146.1mm)
• Maximum Depth: 0.875" (22.2mm)

Measure the tablet with its case, sleeve or skin fitted. The 7"–8" screen-size description is a guide; actual width and depth determine fit. Check that the grips leave buttons and ports accessible.

Specifications

• Holder Hardware Included: 1 x optional tablet tether and 1 x glue tube for the rubber caps, supplied with the UN8 holder
• Ball/Socket Size: B Size, 1" (25.4mm)
• Arm Socket-to-Socket Length: 3" (76.2mm)
• Cup Holder Fit: 2.57"–3.5" (65.3–88.9mm) inside diameter
• Reference Overall Height: 9.15" (232.4mm)
• Materials: High-strength composite and stainless steel
• Weight Capacity: 2 lb (0.91kg) standard use; 1 lb (0.45kg) heavy-duty use. Include the mounted device, case and accessories when checking load.
• Warranty: RAM components are covered by the manufacturer’s limited lifetime warranty terms.

Packaging may vary; all listed components are genuine RAM.

Help

Use the supplied tether where appropriate, check the arm knob and holder retention, and choose a position that keeps the device secure without obstructing controls or visibility. Suitability depends on the actual installation and load.
