RAM-463-TRA1U
RAM C-Size Aluminium Track Ball Base with T-Bolt Attachment (RAM-463-TRA1U)
$41.00$54.00
Size Guide
Included:
- 1 x RAM C-Size Aluminium Track Ball Base with T-Bolt Attachment (RAM-463-TRA1U)
The RAM-463-TRA1U Track Ball is made up of a C size (1.5") ball molded to a marine-grade aluminium base, a rubber friction washer and a stainless steel T-bolt for sliding into virtually any track system. Simply insert or slide the Track Ball into your track and twist the ball clockwise to tighten in place. Twist counterclockwise to loosen or adjust the ball.
The RAM-463-TRA1U is made for use with the RAM Tough-Track system such as the RAP-TRACK-A5U Top-Loading Composite Tough-Track (7").
Features
- Designed for track mounting systems including the RAM® Tough-Track™; includes 1.5" C size rubber ball with pin-lock and 1/4-20" threaded hole with T-bolt
- Features a rubber friction washer and a stainless steel T-bolt; simply insert into your track and twist the ball clockwise to tighten
- Made of marine-grade aluminium, stainless steel components for durability and reliability in the most demanding environments
- Backed by a lifetime warranty
Specifications:
Hardware Included
• (1) Friction washer
• (1) 1/4"-20 x 7/8" T-bolt
Product Dimensions
• Plate diameter: 1.25"
• Thread depth: 0.875"
T-Bolt Dimensions
• 0.48" x 0.95"
Ball Size
• C Size (1.5")
Weight Capacity
• Standard use: 4 lb
• Heavy-duty use: 3 lb
Materials
• Marine-grade aluminium
• Stainless steel
Packaging Type
• Poly bag
Weight
• 0.26 lb
Tough-Tracks:
- RAM 7" Tough-Track (RAP-TRACK-A5U)
- RAM 10.75" Tough-Track (RAP-TRACK-A9U)
- RAM 14.5" Tough-Track (RAP-TRACK-A12U)
